Setup knox over highly available HiveServer2 instances

ENV: HDP 2.5

Please follow following steps to configure

1. under Ambari-> Knox -> Advanced topologies

2. add the following snippet in advanced topologies

<provider>
<role>ha</role>
<name>HaProvider</name>
<enabled>true</enabled>
<param>
<name>HIVE</name>
<value>maxFailoverAttempts=3;failoverSleep=1000;enabled=true;zookeeperEnsemble=rkk3.hdp.local:2181,rkk2.hdp.local:2181,
rkk1.hdp.local:2181;zookeeperNamespace=hiveserver2</value>
</param>
</provider>




comment out the url from hive service tag

<service>
<role>HIVE</role>
<!-- <url>http://{{hive_server_host}}:{{hive_http_port}}/{{hive_http_path}}</url> -->
</service>

3. Restart KNOX

4. Open Beeline and connect to HS2

beeline
Beeline version 1.2.1000.2.5.0.0-1133 by Apache Hive
beeline> !connect jdbc:hive2://rkk1.hdp.local:8443/;ssl=true;sslTrustStore=/var/lib/knox/data-2.5.0.0-1133/security/keystores/gateway.jks;trustStorePassword=knox?hive.server2.transport.mode=http;hive.server2.thrift.http.path=gateway/default/hive
Connecting to jdbc:hive2://rkk1.hdp.local:8443/;ssl=true;sslTrustStore=/var/lib/knox/data-2.5.0.0-1133/security/keystores/gateway.jks;trustStorePassword=knox?hive.server2.transport.mode=http;hive.server2.thrift.http.path=gateway/default/hive
Enter username for jdbc:hive2://rkk1.hdp.local:8443/;ssl=true;sslTrustStore=/var/lib/knox/data-2.5.0.0-1133/security/keystores/gateway.jks;trustStorePassword=knox?hive.server2.transport.mode=http;hive.server2.thrift.http.path=gateway/default/hive: guest
Enter password for jdbc:hive2://rkk1.hdp.local:8443/;ssl=true;sslTrustStore=/var/lib/knox/data-2.5.0.0-1133/security/keystores/gateway.jks;trustStorePassword=knox?hive.server2.transport.mode=http;hive.server2.thrift.http.path=gateway/default/hive: **************
16/11/26 19:58:04 [main]: WARN jdbc.Utils: ***** JDBC param deprecation *****
16/11/26 19:58:04 [main]: WARN jdbc.Utils: The use of hive.server2.transport.mode is deprecated.
16/11/26 19:58:04 [main]: WARN jdbc.Utils: Please use transportMode like so: jdbc:hive2://<host>:<port>/dbName;transportMode=<transport_mode_value>
16/11/26 19:58:04 [main]: WARN jdbc.Utils: ***** JDBC param deprecation *****
16/11/26 19:58:04 [main]: WARN jdbc.Utils: The use of hive.server2.thrift.http.path is deprecated.
16/11/26 19:58:04 [main]: WARN jdbc.Utils: Please use httpPath like so: jdbc:hive2://<host>:<port>/dbName;httpPath=<http_path_value>
Connected to: Apache Hive (version 1.2.1000.2.5.0.0-1133)
Driver: Hive JDBC (version 1.2.1000.2.5.0.0-1133)
Transaction isolation: TRANSACTION_REPEATABLE_READ
0: jdbc:hive2://rkk1.hdp.local:8443/> show tables;
+-----------+--+
| tab_name |
+-----------+--+
| xx |
+-----------+--+
1 row selected (0.201 seconds)
