Optimize your HDFS Rebalancer

[#1]

Summary

It is always a good idea to tune your HDFS Rebalancer away from the raw default values so that the overall hardware will be utilized at an optimal level when HDFS Rebalancing activities are being performed.

Investigation

Configuration Properties

Based on the ​​recommended configurations for the HDFS balancer, we recommend these parameters which we have tested thoroughly in a live production cluster without issue.

DataNode configuration properties

Property	Default	Cloudera Chosen Value
dfs.datanode.balance.max.concurrent.moves	50	100
dfs.datanode.balance.bandwidthPerSec	10MiB	1GiB

Balancer configuration properties

Property	Default	Cloudera Chosen Value
dfs.balancer.moverThreads	1000	4000
dfs.balancer.max-size-to-move	10GB	25GiB
dfs.balancer.getBlocks.min-block-size	10MB	512KiB
rebalancer_threshold	10	5

NameNode Block Placement configuration properties

Based on Block Placement Policies, we also recommend modifying how the NameNode chooses to place blocks during HDFS configuration and rebalancing testing of a heavily heterogeneous cluster.

Property	Default	Cloudera Chosen Value
dfs.block.replicator.classname	n/a	org.apache.hadoop.hdfs.server.blockmanagement.AvailableSpaceBlockPlacementPolicy
dfs.namenode.available-space-block-placement-policy.balanced-space-preference-fraction	0.5	0.7
dfs.namenode.available-space-block-placement-policy.balance-local-node	n/a	false

Avoid Landmines

Some key notes about performing the rebalancing activities after setting the services/disks up:

• Never run both the HDFS && Kudu Rebalancers at the same time
• The contention between both may cause issues
• Perform the Rebalancing activities in the order of Kudu first, HDFS second
• Due to Kudu being unable to track capacity utilization

Performing HDFS Rebalancing Activities

There are corresponding CLI related commands for rebalancing HDFS.  We recommend that you perform these actions from within CM for visibility into the active status of the Rebalancer and to see when the action has been started and completed.

HDFS

Go to CM - Kudu - Actions - Rebalance
