Introduction

It's been a while, but I'm finally finishing this series on Best Mode Quotient. This article is fairly straight forward as we look how to build the infrastructure of model training using Zeppelin and Spark.

Pre-Requisites

In order to run this install, you will have to have deployed a BMQ ephemeral cluster as detailed in this article and this repository.

Moreover you will have to have gathered data on your fitness as explained in part 1 of these series. Based on this data, I created 3 indexes:

  • Intensity Index: How intense was the workout I did that day (based on distance, pace and elevation)
  • Fatigue Index: How much rest I had on that day (based on hours of sleep and rest heart rate)
  • BMQ Index: How my BMQ fairs compare to the max BMQ (5)

You can then agglomerate these 3 indexes, having BMQ and Fatigue on the same day correlating to the Intensity Index of the previous day. All data will be shared in the last article of the series.

You will also notice that the model uses parameterized sleep and rest HR. The whole flow is to be revealed in part 4

Agenda

This tutorial is divided in the following sections:

  • Section 1: Create a mysql interpreter for JDBC in Zeppelin
  • Section 2: Create training set for BMQ prediction
  • Section 3: Create a prediction model
  • Section 4: Save the results in a table

Section 1: Create a mysql interpreter for JDBC in Zeppelin


Login to Zeppelin, then go to top right corner > Admin > Interpreter and edit the jdbc interpreter.

Add the following parameters:

  • mysql.driver: com.mysql.jdbc.Driver
  • mysql.url: jdbc:mysql://localhost:3306/beast_mode_db
  • mysql.user: bmq_user
  • mysql.password: Be@stM0de
  • Add artifact: mysql:mysql-connector-java:5.1.38

Restart the interpreter and you should be good to go.

Section 2: Create training set for BMQ prediction

Create a new note called BMQ Predictions and add the following code, using the jdbc interpreter you just built.

Delete existing training tables if any

%jdbc(mysql)

drop table if exists training_set

Create training set based on fatigue and intensity indexes

%jdbc(mysql)

create table training_set as (
select @rowid:=@rowid+1 as rowid, bmq_index.date, bmq_index, fatigue_index, intensity_index
from bmq_index, fatigue_index, intensity_index, (select @rowid:=0) as init
where bmq_index.date = fatigue_index.date
and date_sub(bmq_index.date, INTERVAL 1 DAY) = intensity_index.date
order by bmq_index.date asc)

View Data

%jdbc(mysql)

select * from training_set

Delete existing prediction tables if any

%jdbc(mysql)

drop table if exists prediction

Create a table we want to apply the algo against

%jdbc(mysql)

create table prediction as (
select date(training_date) as date, estimated_intensity_index,
round((
(1-((select (sleep_hours*60) from PREDICTION_PARAMETERS)/(select max(TOTAL_MINUTES_ASLEEP) from SLEEP_HISTORY)))*0.6 +
(1-((select min(REST_HR) from HEALTH_HISTORY)/(select rest_hr from PREDICTION_PARAMETERS)))*0.4
) *100,2) as estimated_fatigue_index,
0.0 as predicted_bmq
from training_plan)

View Data

%jdbc(mysql)

select * from prediction

Section 3: Create a prediction model

DISCLAIMER: This model needs to be worked on; the purpose of this article is to establish the principal architecture, not give the final most tuned model as I plan on improving on it.

This part uses the spark interpreter of Zeppelin to vectorize, normalize and train a model

Create dataframe from MySQL tables:

%spark2
import org.apache.spark.sql.SQLContext
import org.apache.spark.ml.regression.LinearRegression
import org.apache.spark.ml.feature.Interaction
import org.apache.spark.ml.feature.VectorAssembler
import org.apache.spark.ml.feature.Normalizer

val sqlcontext = new org.apache.spark.sql.SQLContext(sc)

val df = sqlcontext.read.format("jdbc").option("url", "jdbc:mysql://localhost:3306/beast_mode_db").option("driver", "com.mysql.jdbc.Driver").option("dbtable", "training_set").option("user", "bmq_user").option("password", "Be@stM0de").load()

df.show()
%spark2

val target_df = sqlcontext.read.format("jdbc").option("url", "jdbc:mysql://localhost:3306/beast_mode_db").option("driver", "com.mysql.jdbc.Driver").option("dbtable", "prediction").option("user", "bmq_user").option("password", "Be@stM0de").load()
target_df.show()

Vectorize Dataframes

val assembler1 = new VectorAssembler().
  setInputCols(Array( "fatigue_index","intensity_index")).
  setOutputCol("features").
  transform(df)

assembler1.show()
%spark2


val assembler2 = new VectorAssembler().
  setInputCols(Array( "estimated_fatigue_index","estimated_intensity_index")).
  setOutputCol("features").
  transform(target_df)

assembler2.show()

Normalize Dataframes

%spark2
val normalizer = new Normalizer()
  .setInputCol("features")
  .setOutputCol("normFeatures")
  .setP(2.0)
  .transform(assembler1)

normalizer.show()
%spark2

val targetNormalizer = new Normalizer()
  .setInputCol("features")
  .setOutputCol("normFeatures")
  .setP(2.0)
  .transform(assembler2)

targetNormalizer.show()

Train and evaluate Model

%spark2


val Array(trainingData, testData) = normalizer.randomSplit(Array(0.7, 0.3))
%spark2

val lr = new LinearRegression()
  .setLabelCol("bmq_index")
  .setFeaturesCol("normFeatures")
  .setMaxIter(10)
  .setRegParam(1.0)
  .setElasticNetParam(1.0)
val lrModel = lr.fit(trainingData)
lrModel.transform(testData).select("features","normFeatures", "bmq_index", "prediction").show()
%spark2

println(s"Coefficients: ${lrModel.coefficients} Intercept: ${lrModel.intercept}")
%spark2


val trainingSummary = lrModel.summary
println(s"numIterations: ${trainingSummary.totalIterations}")
println(s"objectiveHistory: [${trainingSummary.objectiveHistory.mkString(",")}]")
trainingSummary.residuals.show()
println(s"RMSE: ${trainingSummary.rootMeanSquaredError}")
println(s"r2: ${trainingSummary.r2}")
%spark2

val targetTable = lrModel.transform(targetNormalizer).select("date", "estimated_intensity_index", "estimated_fatigue_index",  "prediction")

targetTable.show()

Section 4: Save the results in a table

Finally, we will take the results of the prediction and put them in a table called BMQ_PREDICTIONS for later use:

Rename the dataframe to match target columns name

%spark2
val newNames = Seq("date", "estimated_intensity_index", "estimated_fatigue_index", "predicted_bmq")
val targetTableRenamed = targetTable.toDF(newNames: _*)

Delete target table if exists

%jdbc(mysql)

drop table if exists BMQ_PREDICTIONS

Write data

%spark2


val prop = new java.util.Properties
prop.setProperty("driver", "com.mysql.jdbc.Driver")
prop.setProperty("user", "bmq_user")
prop.setProperty("password", "Be@stM0de")

targetTableRenamed.write.mode("append").jdbc("jdbc:mysql://localhost:3306/beast_mode_db", "BMQ_PREDICTIONS", prop)

View data

%jdbc(mysql)

select * from BMQ_PREDICTIONS
