Title | Views | Posted |
---|---|---|
4284 | 08-13-2020 07:15 AM |
08-13-2020
07:15 AM
This issue resolved. External ZK did the trick. I am not able to figure the solution with embedded ZK. But using External ZK I am able to achieve the use case which I was trying. Below is link where you will get few more details on this thread, https://stackoverflow.com/questions/63339452/apache-nifi-not-working-with-multiple-notes-in-zookeeper-string Thanks.
... View more
08-07-2020
09:02 PM
Hi @DigitalPlumber , Just to give few more details to above my reply. Below is the version of the Nifi I am using for clustering, Also if you can see in the screenshot, this nifi is in clustered with below entries in configuration file, nifi.properties
nifi.zookeeper.connect.string=192.168.0.10:2182
zookeeper.properties
server.1=192.168.0.10:2777:3777;2182
state-management.xml
<property name="Connect String">192.168.0.10:2182</property> Below below is the screenshot of the clustered node, These all screenshot which I have shared in reply in my both the comments are latest (like are of same day or day before I am commenting). Also on top of it, can you please give me more clarity on zookeeper.properties file node entry. I want to know more about port range which we are providing for node entry, zookeeper.properties
server.1=192.168.0.10:2777:3777;2182 2777:3777 What is use of above port range value ? What is minimum and maximum value for this ? Is it necessary to have difference of 1000 between these ports ? (3777 - 2777 = 1000) If we want to change the value of these port range then what is range of it ? Thanks in advance.
... View more
08-06-2020
09:43 PM
Hi @DigitalPlumber , Thanks for the reply. As I mentioned earlier I am able to achieve Secure Nifi Clustering. But the problem is if first node is removed out of 3 nodes cluster is getting impacted badly with connection loss. And I was trying one more solution like to have same zookeeper string across the cluster. So now in nifi.properties, zookeeper.properties and state-management.xml file having common entry compared to all other nodes. Like below, nifi.properties nifi.state.management.configuration.file=./conf/state-management.xml
# The ID of the local state provider
nifi.state.management.provider.local=local-provider
# The ID of the cluster-wide state provider. This will be ignored if NiFi is not clustered but must be populated if running in a cluster.
nifi.state.management.provider.cluster=zk-provider
# Specifies whether or not this instance of NiFi should run an embedded ZooKeeper server
nifi.state.management.embedded.zookeeper.start=true
# Properties file that provides the ZooKeeper properties to use if <nifi.state.management.embedded.zookeeper.start> is set to true
nifi.state.management.embedded.zookeeper.properties=./conf/zookeeper.properties
# web properties #
nifi.web.https.host=192.168.0.10
nifi.web.https.port=2520
# security properties #
nifi.security.keystore=./ext-lib/ssl/keystore.jks
nifi.security.keystoreType=jks
nifi.security.keystorePasswd=CskME7zgbZiR1k/vwlPJcOayK4VPl3+gVIq/ZgD9c
nifi.security.keyPasswd=CskME7zgbiR1k/vwlPJc3OayK4VP3+gVIq/ZgUD9c
nifi.security.truststore=./ext-lib/ssl/truststore.jks
nifi.security.truststoreType=jks
nifi.security.truststorePasswd=dHNilK1qAKsX5ee3e7gcbg/yQQsVSbUrxGG4Lhr7Y
nifi.security.needClientAuth=true
nifi.security.user.authorizer=managed-authorizer
nifi.security.user.login.identity.provider=file-identity-provider
nifi.security.ocsp.responder.url=
nifi.security.ocsp.responder.certificate=
# cluster common properties (all nodes must have same values) #
nifi.cluster.protocol.heartbeat.interval=5 sec
nifi.cluster.protocol.is.secure=true
# cluster node properties (only configure for cluster nodes) #
nifi.cluster.is.node=true
nifi.cluster.node.address=192.168.0.10
nifi.cluster.node.protocol.port=2510
nifi.cluster.node.protocol.threads=10
nifi.cluster.node.protocol.max.threads=50
nifi.cluster.node.event.history.size=25
nifi.cluster.node.connection.timeout=5 sec
nifi.cluster.node.read.timeout=5 sec
nifi.cluster.node.max.concurrent.requests=100
nifi.cluster.firewall.file=
nifi.cluster.flow.election.max.wait.time=1 mins
nifi.cluster.flow.election.max.candidates=10
# cluster load balancing properties #
nifi.cluster.load.balance.host=
nifi.cluster.load.balance.port=6343
nifi.cluster.load.balance.connections.per.node=4
nifi.cluster.load.balance.max.thread.count=8
nifi.cluster.load.balance.comms.timeout=30 sec
# zookeeper properties, used for cluster management #
nifi.zookeeper.connect.string=192.168.0.10:2182,192.168.0.20:2182,192.168.0.30:2182
nifi.zookeeper.connect.timeout=3 secs
nifi.zookeeper.session.timeout=3 secs
nifi.zookeeper.root.node=/nifi zookeeper.properties initLimit=10
autopurge.purgeInterval=24
syncLimit=5
tickTime=2000
dataDir=./ext-lib/zookeeper-home/zookeeper
autopurge.snapRetainCount=30
server.1=192.168.0.10:2777:3777;2182
server.2=192.168.0.20:2777:3777;2182
server.3=192.168.0.30:2777:3777;2182 state-management.xml <?xml version="1.0" encoding="UTF-8" standalone="yes"?>
<stateManagement>
<local-provider>
<id>local-provider</id>
<class>org.apache.nifi.controller.state.providers.local.WriteAheadLocalStateProvider</class>
<property name="Directory">./state/local</property>
<property name="Always Sync">false</property>
<property name="Partitions">16</property>
<property name="Checkpoint Interval">2 mins</property>
</local-provider>
<cluster-provider>
<id>zk-provider</id>
<class>org.apache.nifi.controller.state.providers.zookeeper.ZooKeeperStateProvider</class>
<property name="Connect String">192.168.0.10:2182,192.168.0.20:2182,192.168.0.30:2182</property>
<property name="Root Node">/nifi</property>
<property name="Session Timeout">10 seconds</property>
<property name="Access Control">Open</property>
</cluster-provider>
</stateManagement> Now after these configuration if I am moved ahead to start the server then I am getting below continuous errors. 2020-08-06 22:55:21,397 ERROR [Curator-Framework-0] o.a.c.f.imps.CuratorFrameworkImpl Background operation retry gave up
org.apache.zookeeper.KeeperException$ConnectionLossException: KeeperErrorCode = ConnectionLoss
at org.apache.zookeeper.KeeperException.create(KeeperException.java:102)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.checkBackgroundRetry(CuratorFrameworkImpl.java:862)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.performBackgroundOperation(CuratorFrameworkImpl.java:990)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.backgroundOperationsLoop(CuratorFrameworkImpl.java:943)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.access$300(CuratorFrameworkImpl.java:66)
at org.apache.curator.framework.imps.CuratorFrameworkImpl$4.call(CuratorFrameworkImpl.java:346)
at java.util.concurrent.FutureTask.run(FutureTask.java:266)
at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.access$201(ScheduledThreadPoolExecutor.java:180)
at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.run(ScheduledThreadPoolExecutor.java:293)
at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
at java.lang.Thread.run(Thread.java:748)
2020-08-06 22:55:21,397 ERROR [Curator-Framework-0] o.a.c.f.imps.CuratorFrameworkImpl Background retry gave up
org.apache.curator.CuratorConnectionLossException: KeeperErrorCode = ConnectionLoss
at org.apache.curator.framework.imps.CuratorFrameworkImpl.performBackgroundOperation(CuratorFrameworkImpl.java:972)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.backgroundOperationsLoop(CuratorFrameworkImpl.java:943)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.access$300(CuratorFrameworkImpl.java:66)
at org.apache.curator.framework.imps.CuratorFrameworkImpl$4.call(CuratorFrameworkImpl.java:346)
at java.util.concurrent.FutureTask.run(FutureTask.java:266)
at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.access$201(ScheduledThreadPoolExecutor.java:180)
at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.run(ScheduledThreadPoolExecutor.java:293)
at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
at java.lang.Thread.run(Thread.java:748)
2020-08-06 22:55:21,399 ERROR [Curator-Framework-0] o.a.c.f.imps.CuratorFrameworkImpl Background operation retry gave up
org.apache.zookeeper.KeeperException$ConnectionLossException: KeeperErrorCode = ConnectionLoss
at org.apache.zookeeper.KeeperException.create(KeeperException.java:102)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.checkBackgroundRetry(CuratorFrameworkImpl.java:862)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.performBackgroundOperation(CuratorFrameworkImpl.java:990)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.backgroundOperationsLoop(CuratorFrameworkImpl.java:943)
at org.apache.curator.framework.imps.CuratorFrameworkImpl.access$300(CuratorFrameworkImpl.java:66)
at org.apache.curator.framework.imps.CuratorFrameworkImpl$4.call(CuratorFrameworkImpl.java:346) Above are infinite logs and even it will start the Nifi. Once I am trying to access the nifi from the browser then I am getting cluster connection error message. Please see below screenshot for your reference. Its quite surprising for me. As If I am starting the server with in cluster with single zookeeper string, I am able to start without any issue. Single node is getting into cluster properly. nifi.properties
nifi.zookeeper.connect.string=192.168.0.10:2182
zookeeper.properties
server.1=192.168.0.10:2777:3777;2182
state-management.xml
<property name="Connect String">192.168.0.10:2182</property> But When I am moving ahead to add more than one node it is failing. nifi.properties
nifi.zookeeper.connect.string=192.168.0.10:2182,192.168.0.20:2182,192.168.0.30:2182
zookeeper.properties
server.1=192.168.0.10:2777:3777;2182
server.2=192.168.0.20:2777:3777;2182
server.3=192.168.0.30:2777:3777;2182
state-management.xml
<property name="Connect String">192.168.0.10:2182,192.168.0.20:2182,192.168.0.30:2182</property> I have followed all the steps for the same. If I missed out any of the step then even I won't be able to achieve 1 scenario. Please let me know if I am missing anything. If I am missing any of the configuration then of course it will be really very silly mistake which I am not able to figure it out for now. :). Again thanks @DigitalPlumber for taking out time and replying on this thread. Please let me know what solution will work for this. Thanks in advance.
... View more
08-05-2020
07:18 AM
I want to setup cluster of 3 nodes. Suppose below are the 3 nodes,
Node 1 = 192.168.0.10
Node 2 = 192.168.0.20
Node 3 = 192.168.0.30
I am able to setup the cluster by using below zookeeper string in the respective nodes,
Node 1 = 192.168.0.10:2181
Node 2 = 192.168.0.10:2181,192.168.0.20:2181
Node 3 = 192.168.0.10:2181,192.168.0.20:2181,192.168.0.30:2181
If Node 1 is up and running and I am turning of any other node than Node 1, then cluster is working without any issue.
But problem with above configuration is, if I am turning off the Node 1 (192.168.0.10), then cluster is failing with the connection loss status. As Node 2 and Node 3 waiting for Node 1 which is down which turns into cluster failure.
So I am trying to setup same zookeeper string for all the node at once and trying to start server one by one.
Node 1 = 192.168.0.10:2181,192.168.0.20:2181,192.168.0.30:2181
Node 2 = 192.168.0.10:2181,192.168.0.20:2181,192.168.0.30:2181
Node 3 = 192.168.0.10:2181,192.168.0.20:2181,192.168.0.30:2181
So now Node 2 and Node 3 is already down (like never started). And I am trying to start Node 1 with zookeeper string "192.168.0.10:2181,192.168.0.20:2181,192.168.0.30:2181".
Node 1 not starting it all.
I am kind of new to the Nifi and working on clustering part. I am able to achieve all the clustering activity by taking reference of available resources and by doing some POC work. But only this is problem where I stuck and not able to move ahead.
I am using SSL Nifi Clustering. Can anyone please help me out with this ? Thanks in advance.
